LED Framing 800w

  • Model : R-LPM800
  • Product description:With Pro Module LED 800w engine,beam angle zooming 5° - 50°,CMY + CTO Colormix system . 4 individual framing shutters/blades.
  • INQUIRY

Light Source: 800W White LED,  34000 lm ,ColorTemp 7000K
Average LED Life: 20,000 Hour
Input Voltage: 100-240VAC, 50/60Hz
Power Consumption: 980W max. at full output
Zoom: 5° - 50° linear motorized
Prism: 3-facet circular prism, and 6-linear prism

Frost: Frost filter hybrid wash effect

Strobe: 0-25Hz variable speed, pulse and random strobe

Dimmer: 0-100% variable linear dimming curves

CRI Filter: CRI
90

Shutters: 4 independent framing shutters

System Rotation:+/- 90
°

7 Dichoric Colors plus open, Index / Bi-directional rotating rainbow effect

CMY + CTO Colormix system
CT 2700K - 6500K

DMX Channel: 36CHs

Control Mode: DMX, RDM, (Optional ARTNET
)
Full Color 180
° Reversible LCD

3 pin or 5pin DMX In/Out

PowerCON Power In
/out
Net Weight: 31kg
s
Dimension: 40
×29×75CM
